MSI Modern AM242 1M Core 5 120U, 8GB, 512GB, Win 11 Pro All-in-one, Black
Key Specifications
Choose one or multiple features to search for items that have the same specifications.| Technical details | |
| Device type | SSD |
| Processor | |
| Processor model | 120U |
| Processor manufacturer | Intel |
| Processor family | Intel Core 5 |
| Processor cores | 10 |
| Processor threads | 12 |
| Processor boost frequency | 5 GHz |
| Processor cache | 12 MB |
| Processor frequency | 1.4 GHz |
| Processor cache type | Smart Cache |
| Efficient cores | 8 |
| Performance cores | 2 |
| Processor base power | 15 W |
| Maximum turbo power | 55 W |
| Efficient-core base frequency | 0.9 GHz |
| Performance-core base frequency | 1.4 GHz |
| Processor generation | Intel Core (Series 1) |
| Efficient-core Max Turbo Frequency | 3.8 GHz |
| Performance-core Max Turbo Frequency | 5 GHz |
| Hard drive | |
| Total storage capacity | 512 GB |
| Memory | |
| Internal memory type | DDR5-SDRAM |
| Memory slots | 2 |
| Maximum internal memory | 64 GB |
| Memory clock speed | 5600 MHz |
| Memory form factor | DIMM/SO-DIMM |
| Memory slots type | SO-DIMM |
| Memory layout (slots x size) | 1 x 8 GB |
| Internal memory | 8 GB |
| Display | |
| Pixel pitch | 0.2745 x 0.2745 mm |
| Display diagonal | 60.5 cm (23.8") |
| Display brightness | 250 cd/m² |
| Display resolution | 1920 x 1080 pixels |
| Tilt angle range | -5 - 15° |
| Touchscreen | ![]() |
| Tilt adjustment | ![]() |
| Anti-glare screen | ![]() |
| HD type | Full HD |
| Panel type | IPS |
| Audio | |
| RMS rated power | 5 W |
| Built-in speaker(s) | ![]() |
| Number of speakers | 2 |
| Audio chip | Realtek ALC256 |
| Ports & interfaces | |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 1 |
| Microphone in | ![]() |
| DVI port | ![]() |
| HDMI ports quantity | 2 |
| Combo headphone/mic port | ![]() |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| USB4 Gen 3x2 ports quantity | 0 |
| Weight & dimensions | |
| Height | 493 mm |
| Width | 631 mm |
| Depth | 170 mm |
| Package depth | 170 mm |
| Package height | 493 mm |
| Package width | 631 mm |
| Energy management | |
| AC adapter power | 120 W |
| Power supply | 120 W |
| Operational conditions | |
| Operating relative humidity (H-H) | 0 - 85% |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 35 °C |
| Storage relative humidity (H-H) | 0 - 90% |
| Networking | |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Bluetooth version | 5.3 |
| Ethernet LAN | ![]() |
| Bluetooth | ![]() |
| Wi-Fi | ![]() |
| Ethernet LAN data rates | 1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| WLAN controller manufacturer | Intel |
| Storage | |
| Drive capacity | 512 GB |
| Optical drive type | No |
| Card reader integrated | ![]() |
| Number of SSDs installed | 1 |
| Storage media | SSD |
| SSD form factor | M.2 |
| NVMe | ![]() |
| Total SSDs capacity | 512 GB |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Certificates | |
| Certification | FCC, CB/CE, UL & CUL, VCCI, RCM |
| Operating system/software | |
| Operating system installed | Windows 11 Pro |
| Operating system architecture | 64-bit |
| Camera | |
| Built-in camera | ![]() |
| Packaging content | |
| Mouse included | ![]() |
| Keyboard included | ![]() |
| Other features | |
| Warranty period | 2 year(s) |
| Design | |
| Chassis type | All-in-One |
| Cable lock slot | ![]() |
| Product colour | Black |
| Panel mounting interface | 75 x 75 mm |
| Product type | All-in-One PC |
| Cable lock slot type | Kensington |
| VESA mounting | ![]() |
| Graphics | |
| On-board graphics card model | Intel Graphics |
| Discrete graphics card model | Not available |
| On-board graphics card | ![]() |
| Discrete graphics card | ![]() |
| On-board graphics card family | Intel Graphics |
| On-board GPU manufacturer | Intel |
| Performance | |
| Motherboard chipset | Intel SoC |
| Market positioning | Business |
| Product type | All-in-One PC |
| EAN | 4711377232036 |
| Warranty | 2 years |
The MSI Modern AM242 1M is an All-in-One PC that integrates computer components directly into a 23.8-inch display, creating a compact footprint suitable for business environments. Its hardware configuration is specified for productivity tasks, including document editing, web browsing, and managing multiple applications concurrently. The system utilizes a 512 GB solid-state drive, which provides faster system boot times and application loading compared to traditional hard disk drives. This combination of processing and storage supports a consistent workflow for daily business operations and multitasking demands.
This model is built around an Intel Core 5 120U processor and 8 GB of DDR5 memory. Visuals are managed by the integrated Intel Graphics chipset, which is sufficient for standard office applications and video conferencing. For network connectivity, the system includes support for Wi-Fi 6E, a Gigabit Ethernet port for wired connections, and Bluetooth 5.3 for pairing wireless peripherals. The unit provides two HDMI ports for extended display output, two USB 2.0 ports for legacy devices, and operates on the Windows 11 Pro platform.
Key Features:- 23.8-inch Full HD (1920 x 1080) display
- Intel Core 5 120U processor with 10 cores and 12 threads
- 8 GB of DDR5 5600 MHz installed memory
- 512 GB solid-state drive storage capacity
- Integrated Intel Graphics for visual output
- Pre-installed with the Windows 11 Pro operating system
- Connects via Wi-Fi 6E, Gigabit Ethernet, and Bluetooth 5.3
- Equipped with 2 USB 2.0 ports and 2 HDMI outputs
- All-in-One chassis measuring 631 x 170 x 493 mm
- Powered by a 120 W power supply
