Cooler Master XG650 650W - Power supply, 80 Plus Platinum

Manufacturer: COOLER MASTER
ID: MPG-6501-AFBAP-EU
Choose the version of your product
21490€ Show VAT 0% Show VAT 25,5%
Estimated delivery: No delivery info
Currently unavailable
Select your store
Not in stock Open today: 10:00 - 18:00 About this store
Not in stock Open today: 09:00 - 17:00 About this store
Not in stock Open today: 10:00 - 18:00 About this store
Not in stock Open today: 10:00 - 17:00 About this store
Not in stock Open today: 10:00 - 18:00 About this store
Not in stock Open today: 10:00 - 17:00 About this store
Not in stock Open today: 10:00 - 18:00 About this store
Multitronic warehouse store
Multitronic | JNT Pietarsaari
Multitronic Seinäjoki
Multitronic | iTronic Jyväskylä
Multitronic | iTronic Lappeenranta
Multitronic Mariehamn
iTronic Vaasa

Key Specifications

Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Technical details
Sustainability compliancecheckmark
Sustainability certificatesErP
Ports & interfaces
Motherboard power connector24-pin ATX
Number of SATA power connectors8
Peripheral (Molex) power connectors (4-pin)4
EPS power connector (8-pin)checkmark
PCI Express power connectors (6+2 pin)4
Cabling typeModular
Motherboard power cable length65 cm
SATA power cable length500,620,740,860 mm
Peripheral (Molex) power cable length860,740,620,500 mm
PCI Express power cable length67 cm
EPS power connector (4+4 pin)checkmark
Weight & dimensions
Height86 mm
Width150 mm
Depth160 mm
Energy management
Input current4 - 8 A
Nominal power650 W
Efficiency92%
Hold time20 ms
Power protection featuresOver current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)120 W
Combined power (+12V)650 W
Combined power (+5V)120 W
Combined power (-12V)3.6 W
Combined power (+5Vsb)15 W
Max output current (+3.3V)20 A
Max output current (+12V)54.1 A
Max output current (+5V)20 A
Max output current (-12V)0.3 A
Max output current (+5Vsb)3 A
AC input frequency50 - 60 Hz
AC input voltage100 - 240 V
Total power650 W
Power Good signal delay range100 - 150 ms
Operational conditions
Operating temperature (T-T)0 - 50 °C
Packaging data
Package depth300 mm
Package height125 mm
Package width214 mm
Certificates
80 PLUS certification80 PLUS Platinum
Other features
EPS cable length65 cm
Design
Product colourBlack
Number of fans1 fan(s)
Cooling typeActive
Fan diameter13.5 cm
Fan speed0 - 1800 RPM
Performance
CertificationTUV, cTUVus, BSMI, FCC, CCC, EAC, UKCA
Mean time between failures (MTBF)100000 h
Noise level25 dB
PurposePC
ATX version2.53
Power supply unit (PSU) form factorATX
Logistics data
Master (outer) case height250 mm
Master (outer) case width318 mm
Master (outer) case length520 mm
Products per master (outer) case4 pc(s)
EAN4719512111925
Warranty1 year

Silence Is Platinum
With a focus on thermal dissipation and maximized efficiency, this platform allows Cooler Master to offer an entirely new class of high efficiency products with 100% Japanese capacitors, boasting top-shelf performance with reduced ripple noise.

First In-house Design Platform
Cooler Master keeps searching for uniqueness, creativity, and more. XG Platinum is the first Cooler Master in-house designed power supply, providing next-level efficiency, rigid design, and sturdy performance to fulfill all your daily computing and gaming needs.

Crafted For Excellence
This professional grade power supply unit is built with full-bridge LLC resonant converter and DC-DC technology, made for the all users providing stability, reliability and so much more.

Silence is Platinum
XG650 Platinum offers smart thermal control mode which you can do more with your system in the minimal level of noise generated by the silent fan.

Fan Up, Fan Down
Both side panels on the XG Platinum are embossed with a stylish silk screen printed design. Install your PSU in either a fan up or fan down orientation while retaining 100% of the unit's aesthetic value anytime, anywhere.

Build Your Way
Every facet of the XG Platinum was chosen with the goal of maximizing efficiency and thermal performance. Full modular cables were a must so that users could minimize the number of cables in their system based on their needs, reducing clutter and increasing both airflow and aesthetic quality.
