Seasonic Focus GX White - 1000W ATX 3.1
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Technical details | |
Sustainability compliance | ![]() |
Sustainability certificates | ENERGY STAR, ErP |
Ports & interfaces | |
PCI Express connector | ![]() |
Motherboard power connector | 24-pin ATX |
CPU power connector (4+4 pin) | ![]() |
PCI Express power connectors (6+2 pin) | 2 |
Cabling type | Fully-Modular |
Motherboard power cable length | 61 cm |
SATA power cable length | 950 mm |
CPU power cable length | 70 cm |
Peripheral (Molex) power cable length | 690 mm |
PCI Express power cable length | 75 cm |
PCI Express power connectors (12+4 pin) cable length | 700 mm |
Weight & dimensions | |
Height | 86 mm |
Width | 150 mm |
Depth | 140 mm |
Energy management | |
Input current | 10 - 5 A |
Nominal power | 1000 W |
Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Combined power (+3.3V) | 100 W |
Combined power (+12V) | 744 W |
Combined power (+5V) | 100 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 62 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Total power | 750 W |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Certificates | |
Certification | BSMI, CB, CCC, CE, cTUVus, EAC, FCC, TUV, Energy Star, ErP Lot 6, REACH, RoHS, WEEE |
Waste Electrical and Electronic Equipment (WEEE) compliance | ![]() |
Packaging content | |
Cable tie(s) included | ![]() |
Design | |
Product colour | White |
Number of fans | 1 fan(s) |
On/off switch | ![]() |
Cooling type | Active |
Fan diameter | 13.5 cm |
Performance | |
Mean time between failures (MTBF) | 100000 h |
Purpose | PC |
Bearing technology | FDB |
ATX version | 3.1 |
80 PLUS certification | 80 PLUS Gold |
Silent mode | ![]() |
Power supply unit (PSU) form factor | ATX |
EAN | 4711173878551 |
FOCUS GX ATX 3.0
Following the well-established legacy of the Seasonic FOCUS Series, the FOCUS GX Series was upgraded to comply with the ATX 3.0 and PCIe 5.0 standards. Offering a complete range of power supplies ranging from 750 W to 1000 W with in a 140 mm depth, these units will be the perfect allies to power the newest high power graphics cards and processors on the market.
Digital Hybrid Fan Control
The industry’s first, Seasonic patented, advanced three-phased thermal control achieves optimal between silence and cooling. This Digital Hybrid Fan Control functions in three operational stages: Fanless Mode, Silent Mode, and Cooling Mode.
Reduced noise without increase in temperature
Extended fan life due to the reduced number of fan rotations
Optimized heat dissipation at all times
Unsurpassed silent performance in Fanless Mode
Fluid Dynamic Fan Bearing
High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan.
When the fan shaft rotates, high pressure oil drifts along the grooves of the bearing sleeve to generate a thin layer of lubrication between the bearing faces.
As the speed increases, so does dynamic oil pressure and the shaft is lifted from the bearing to create smooth, effortless rotations. The herringbone shape of the groves helps to efficiently channel the lubricant and avert leakage.
