Thermaltake Smart BX3 650W - power supply, 80 Plus Bronze
Key Specifications
Choose one or multiple features to search for items that have the same specifications.Ports & interfaces | |
ATX Power connector (24-pin) | |
PCI Express connector | |
Number of SATA power connectors | 4 |
Peripheral (Molex) power connectors (4-pin) | 4 |
CPU P4 connector (4-pin) | 2 |
PCI Express power connectors (6+2 pin) | 2 |
Cabling type | Non-Modular |
Peripheral (Molex) power cable length | 150,500 mm |
Weight & dimensions | |
Height | 140 mm |
Width | 150 mm |
Depth | 86 mm |
Energy management | |
Peak power | 650 W |
Input current | 15 A |
Nominal power | 650 W |
Hold time | 150 ms |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 110 W |
Combined power (+12V) | 650 W |
Combined power (+5V) | 110 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 18 A |
Max output current (+12V) | 54.2 A |
Max output current (+5V) | 18 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 3 A |
AC input frequency | 50/60 Hz |
AC input voltage | 100 - 240 V |
Total power | 650 W |
Certificates | |
80 PLUS certification | 80 PLUS Bronze |
Design | |
Product colour | Black |
Fan diameter | 12 cm |
Performance | |
Purpose | PC |
ATX version | 3.1 |
80 PLUS certification | 80 PLUS Bronze |
Silent mode | |
Power supply unit (PSU) form factor | ATX |
EAN | 4711475643048 |
Unmatched Reliability ATX 3.1 Power Supply
The Smart BX3 series is designed to meet ATX 3.1 standards, offering 550W, 650W, and 750W options. It's perfect for budget-conscious users seeking an efficient and reliable entry-level power supply, backed by a solid 5-year warranty.
ATX 3.1 Ready
Smart BX3 series is fully compatible with ATX 3.1 specifications which supports up to 200% power excursion, reaches 60% low load efficiency and complies with required power supply timing standards.
Be Smart, Stay Quiet
Equipped with a 120mm fluid bearing fan for superior airflow. Additionally, the built-in Smart Zero Fan spins only when the load reaches a certain percentage to minimize unwanted noise.
High Quality 105°C/221°F Main Capacitor
High quality main capacitor greatly improves the power supplies durability and ensures the Smart BX3 series is stable and reliable.
High Amperage Single +12V Rail & DC to DC Design
Powerful single +12V rail can properly deliver the power you need for the best compatibility. The use of DC to DC circuit design provides very stable operation and enhanced voltage regulation.
Non-Modular Flat Cable Design
Smart BX3 series comes with soft black cables, designed to make cable installation an easy task while fully powering the system at optimal voltages.
