Key Specifications
Choose one or multiple features to search for items that have the same specifications.Weight & dimensions | |
Package weight | 1.92 kg |
Package depth | 205 mm |
Package height | 137 mm |
Package width | 322 mm |
Radiator width | 27.4 cm |
Radiator depth | 12 cm |
Radiator height | 2.7 cm |
Tube length | 40 cm |
Fan dimensions (W x D x H) | 120 x 120 x 26 mm |
Energy management | |
Pump voltage | 12 V |
Pump current | 0.7 mA |
Fan voltage | 12 V |
Fan current | 0.38 A |
Thermal Design Power (TDP) | 360 W |
Packaging content | |
Manual | |
Other features | |
Tube material | Rubber |
Thermal grease | |
Design | |
Product colour | White |
Number of fans | 2 fan(s) |
Illumination colour | Multi |
Fan connector | 3-pin + 4-pin |
Radiator material | Aluminum |
Illumination LED | |
Performance | |
Type | Liquid cooling kit |
Mean time between failures (MTBF) | 50000 h |
Fan diameter | 12 cm |
Supported processor sockets | LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), Socket AM3, Socket AM4, Socket AM5, Socket FM1, Socket FM2 |
Suitable location | Processor |
Maximum airflow | 79.8 cfm |
Minimum airflow (imperial) | 39 cfm |
Minimum air pressure | 0.67 mmH2O |
Maximum air pressure | 3.6 mmH2O |
Fan speed (max) | 2000 RPM |
Fan speed (min) | 500 RPM |
Bearing type | Ceramic bearing |
Quantity per pack | 1 pc(s) |
Fan noise level (min) | 15 dB |
Fan noise level (max) | 32.6 dB |
Pulse-width modulation (PWM) support | |
Fan's mean time to failure (MTTF) | 100000 h |
EAN | 4713157727183 |
Source: Icecat.biz |
Luminous Aurebelt™ and Infinite RGB Reflection
Premium water block equipped with Luminous Aurabelt™ technology and unique Infinite RGB Reflection for a visually stunning experience
ENERMAX SquA RGB ADV Fans
Designed for aesthetics with incredible stunning RGB hub lighting effect
Optimal cooling performance with Vortex Frame Technology and a downsized hub design
Patented Dual Chamber Water Block Design
Patented Dual-chamber Mechanism that isolates the pump from the heat, significantly increases the cooler’s lifespan without compromising efficiency
Patented CCI + SCT Technology
Central Coolant Inlet (CCI) technology injects the coolant at the hottest spot to prevent heat surges
Shunt-channel Technology (SCT) design shortens the coolant flow path, resulting in faster heat transfer
Addressable RGB Lighting Synchronization
AQUAFUSION ADV is designed to synchronize to addressable RGB motherboards (3 pin assignment is 5V/D/G) which users can program preferred lighting effects via motherboard software
2 Ways to Control RGB Lighting Effects
Motherboard Synchronization
Coordinate your visual effects through supported RGB software and motherboard synchronization to access control for customized lighting effects
ENERMAX RGB Control Box
Preset 10 lighting effects; use the attached ENERMAX RGB control box to select your preferred lighting mode, brightness and speed
Robust Weaved Tubing
Premium 400mm weaved tubing is perfect for mainstream system builds
Premium Aluminum Radiator Channels
The channels on the radiator are meticulously designed, combined with thin aluminum fins to deliver high heat exchange capacity
