EVGA SuperNova 750 GT 750W - PSU, 80 Plus Gold

Technical details
Sustainability compliance
Ports & interfaces
ATX Power connector (24-pin)
Floppy disk drive connector
Motherboard power connector	24-pin ATX
Number of SATA power connectors	6
Peripheral (Molex) power connectors (4-pin)	3
CPU power connector (4+4 pin)
PCI Express power connectors (6+2 pin)	4
Cabling type	Modular
SATA power cable length	550,650,750 mm
CPU power cable length	70 cm
Peripheral (Molex) power cable length	550,650,750 mm
PCI Express power cable length	85 cm
EPS power connector (4+4 pin)
Weight & dimensions
Height	86 mm
Width	150 mm
Depth	150 mm
Energy management
Nominal power	750 W
Efficiency	90%
Power protection features	Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Combined power (+3.3V)	130 W
Combined power (+12V)	750 W
Combined power (+5V)	130 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+12V)	62.5 A
Max output current (+5V)	20 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	3 A
AC input frequency	50 - 60 Hz
AC input voltage	100 - 240 V
Total power	750 W
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Packaging data
Package type	Box
Certificates
80 PLUS certification	80 PLUS Gold
Packaging content
Cables included	AC
Design
Product colour	Black
Number of fans	1 fan(s)
Cooling type	Active
Fan diameter	13.5 cm
Fan location	Top
Performance
Certification	TUV, CB, FCC, RCM, cTUVus, CCC, WEEE
Purpose	PC
Bearing technology	Ball bearing
Power supply unit (PSU) form factor	ATX
Logistics data
Harmonized System (HS) code	84733020
EAN	4250812432049
Warranty	1 year

REFINEMENT IN PERFORMANCE AND DESIGN
Upgrade both aesthetics and electronic components with a unique radial design fan grill, compact 150mm length and width, and 100% Japanese capacitors.

80 PLUS GOLD EFFICIENCY
80 PLUS Gold Certified. Ensures that your power supply is 90% efficient or higher.

FLUID DYNAMIC BEARING
The EVGA SuperNOVA GT uses a long-life 135mm fan with a Fluid Dynamic Bearing (FDB) for silence, reliability, and a longer life expectancy.

SINGLE +12V OUTPUT
Provides a stable output for compatibility with the latest hardware.

FULLY MODULAR DESIGN
Choose the cables you need to make cable management simple and clean.

AUTO ECO MODE
Fan RPM adapts to the PSU temperature. The fan will shut off in a low temperature/low load environment, resulting in reduced noise.

Full Protection
- OVP Over Voltage Protection
- OCP Over Current Protection
- OPP Over Power Protection
- SCP Short Circuit Protection
- UVP Under Voltage Protection
- Dual OTPOver Temperature Protection on the Primary and Secondary PCB
