Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Ports & interfaces | |
PCI Express connector | |
Motherboard power connector | 20+4 pin ATX |
Floppy drive power connector | 1 |
Number of SATA power connectors | 9 |
Peripheral (Molex) power connectors (4-pin) | 3 |
CPU power connector (4+4 pin) | |
PCI Express power connectors (6+2 pin) | 2 |
Cabling type | Fully-Modular |
Motherboard power cable length | 65 cm |
SATA power cable length | 500,650,800 mm |
CPU power cable length | 80 cm |
Peripheral (Molex) power cable length | 500,650,800,950 mm |
PCI Express power cable length | 50 cm |
Weight & dimensions | |
Weight | 2.2 kg |
Height | 86 mm |
Width | 150 mm |
Depth | 140 mm |
Energy management | |
Input current | 10 A |
Nominal power | 650 W |
Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 100 W |
Combined power (+12V) | 648 W |
Combined power (+5V) | 100 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 54 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
AC input frequency | 47 - 63 Hz |
AC input voltage | 100 - 240 V |
Total power | 650 W |
Packaging data | |
Package weight | 2.75 kg |
Certificates | |
80 PLUS certification | 80 PLUS Gold |
Design | |
Product colour | Black |
Number of fans | 1 fan(s) |
Cooling type | Active |
Fan diameter | 12 cm |
Performance | |
Certification | 80PLUS Gold |
Purpose | PC |
ATX version | 2.53 |
Power supply unit (PSU) form factor | ATX |
EAN | 753263077189 |
Warranty | 5 years |
With the PowerUp series, Chieftec aims to bring the well-received technical quality and high performance of the PowerPlay series to the mainstream gamer’s market. With modern full-bridge LLC and DC-to-DC technology, extremely low ripple values and tight voltage regulation can be achieved.
A high power-density design allows this series to deliver up to 850W of power in a compact form factor, measuring only 14 cm in total length, while achieving 80 PLUS® Gold certified efficiency. The compact size combined with the fully modular cable management, allows the PowerUp series to be used conveniently in smaller builds, where a short PSU is needed, while long, flat, black cables support builds even in very large gaming cases.
