Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
| Ports & interfaces | |
| PCI Express connector |  |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| EPS power connector (8-pin) | |
| ATX power connector (20+4 pin) |  |
| PCI Express power connectors (8-pin) | 1 |
| CPU power connector (4+4 pin) | |
| PCI Express power connectors (6+2 pin) | 1 |
| Cabling type | Non-Modular |
| Weight & dimensions | |
| Weight | 1.7 kg |
| Height | 86 mm |
| Width | 150 mm |
| Depth | 140 mm |
| Energy management | |
| Input current | 12 A |
| Nominal power | 650 W |
| Hold time | 500 ms |
| Power protection features | No load operation, Over current, Over power, Over voltage, Short circuit, Surge & inrush protection (SIP), Under voltage |
| Power Factor Correction (PFC) type | Active |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 650 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Packaging data | |
| Package weight | 1.9 kg |
| Package depth | 255 mm |
| Package height | 100 mm |
| Package width | 195 mm |
| Certificates | |
| RoHS compliance | |
| Compliance certificates | BIS, BSMI, CB, CE, Federal Communications Commission (FCC), ICES, KC, RCM, UKCA, cTUVus |
| Design | |
| Product colour | Black |
| Illumination | |
| Fan diameter | 12 cm |
| Performance | |
| Form factor | ATX |
| Noise level | 0 dB |
| Purpose | PC |
| Supported motherboard form factors | ATX |
| 80 PLUS certification | 80 PLUS Bronze |
| Silent mode | |
| Power supply unit (PSU) form factor | ATX |
| EAN | 0761345201070 |
The Antec CSK650DC EC is a 650-watt power supply unit designed for standard ATX-based computer systems. It provides a continuous power output suitable for mid-range builds with single-GPU configurations. The unit features Active Power Factor Correction (PFC) to maintain stable voltage delivery to connected components. Its non-modular cabling design means all necessary wires are permanently attached, which may require careful routing for clean system interiors.
This PSU is housed in a standard ATX enclosure measuring 150 x 140 x 86 mm, ensuring compatibility with most PC cases. Thermal management is handled by a single 120mm fan designed to cool the internal components during operation. The unit includes a comprehensive set of electrical protections, such as Over Voltage Protection (OVP), Under Voltage Protection (UVP), Over Power Protection (OPP), and Short Circuit Protection (SCP), to safeguard hardware from power irregularities.
Key Features:- Total power output of 650W
- ATX form factor
- Non-modular cable design
- Cooled by a 120mm fan
- One 20+4 pin ATX motherboard connector
- One 4+4 pin CPU connector
- One 6+2 pin and one 8-pin PCIe connectors
- Six SATA power connectors
- Features active Power Factor Correction (PFC)
- Dimensions of 150 x 140 x 86 mm
- Weighs 1700 g
