Ubiquiti 10 Gbps Cloud Gateway with 200+ UniFi device 2000+ clients
Manufacturer: UBIQUITI NETWORKS
ID: UDM-PRO-MAX
67690€
Show VAT 0%
Show VAT 25,5%
Multitronic Vaasa
Multitronic Pietarsaari
Multitronic Jyväskylä
Multitronic Lappeenranta
Multitronic Mariehamn
Key Specifications
Choose one or multiple features to search for items that have the same specifications.
Specifications
Description
Store availability
Delivery
Price development
Manuals
| Technical details | |
| Device type | SSD |
| Ports & interfaces | |
| WAN connection | Ethernet (RJ-45), SFP+ |
| Ethernet LAN (RJ-45) ports | 9 |
| Gigabit Ethernet (copper) ports quantity | 1 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Basic switching RJ-45 Ethernet ports quantity | 9 |
| SFP+ module slots quantity | 2 |
| Power connector | DC-in jack |
| 2.5G Ethernet (copper) ports quantity | 1 |
| SFP+ ports quantity | 2 |
| Weight & dimensions | |
| Weight | 4.7 kg |
| Height | 43.7 mm |
| Width | 442.4 mm |
| Depth | 285.6 mm |
| Energy management | |
| Number of power supply units | 1 |
| Power source | AC/DC |
| Input voltage | 100 - 240 V |
| Heat dissipation | 205 BTU/h |
| Input frequency | 50/60 Hz |
| Power over Ethernet (PoE) |  |
| Redundant power supply (RPS) support |  |
| Input current | 2 A |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| DC input voltage | 12 V |
| Power consumption (max) | 60 W |
| Power supply included | |
| Electrostatic Discharge (ESD) protection (air) | 15 kV |
| Electrostatic Discharge (ESD) protection (contact) | 8 kV |
| Electromagnetic (EMP) protection | |
| Electromagnetic (EMP) protection (air) | 15 kV |
| Electromagnetic (EMP) protection (contact) | 8 kV |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -10 - 40 °C |
| Protocols | |
| Routing protocols | OSPF, BGP |
| DHCP server | |
| Networking | |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| VLAN support | |
| 10G support | |
| |
| Virtual LAN features | IP subnet–based VLAN |
| Data transmission | |
| Throughput | 5 Gbit/s |
| Security | |
| Firewall security | Yes |
| VLAN support | |
| IGMP proxy | |
| DHCP features | DHCP relay, DHCP server |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Management features | |
| Quality of Service (QoS) support | |
| Multicast support | |
| Switch type | Managed |
| Reset button | |
| Packaging content | |
| Cables included | AC |
| User guide | |
| Rack mount kit | |
| Design | |
| Rack mounting | |
| Form factor | 1U |
| LED indicators | Activity, Error, Link, Ready |
| Product colour | Grey |
| Rack capacity | 1U |
| Stackable | |
| Reset button | |
| Housing material | Aluminium, Galvanized steel |
| Mounting type | Rack mounting |
| Display type | LCM |
| Enclosure material | Aluminium/SGCC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | |
| Performance | |
| Drive capacity | 128 GB |
| Processor frequency | 2000 MHz |
| Internal memory | 8000 MB |
| Processor model | ARM Cortex-A57 |
| Flash memory | 32000 MB |
| Number of processors installed | 1 |
| Memory type | DDR4-SDRAM |
| Processor manufacturer | ARM |
| Processor family | ARM Cortex |
| Built-in processor | |
| Display type | LCM |
| Control display unit | |
| Sustainability | |
| Sustainability compliance | |
| EAN | 8100846932540 |
| Warranty | 2 years |
| Source: Icecat.biz | |
Professional-grade, rack-mount Cloud Gateway with 10 Gbps performance, multi-WAN load balancing, and two NVR drive bays designed for large-scale, multi-application UniFi sites.
