ASRock Radeon RX 7700 XT Challenger 12GB OC Graphics Card

The ASRock Radeon RX 7700 XT Challenger 12GB is a graphics card based on the AMD RDNA 3 architecture. This unit incorporates 3456 stream processors and 54 ray accelerators to manage gaming and rendering tasks. It comes equipped with 12GB of GDDR6 video memory and a 192-bit memory bus, providing a memory clock speed of 18000 MHz. The card supports a maximum digital resolution of 7680 x 4320 pixels, enabling output for high-resolution displays and multi-monitor setups.

Physical dimensions for this model include a length of 266 mm and a height of 130 mm, requiring two expansion slots for installation. Thermal management is handled by an active cooling system featuring two fans designed for consistent airflow over the heatsink. The hardware supports up to four simultaneous displays via three DisplayPort 2.1 and one HDMI 2.1 outputs. For power delivery, the card utilizes two 8-pin supplementary connectors and requires a system power supply of at least 750W.

• The graphics processor family is AMD
• This model uses the Radeon RX 7700 XT GPU
• Integrated video memory is 12 GB GDDR6
• The memory bus operates at 192-bit
• The boost clock speed reaches 2854 MHz
• The hardware contains 3456 stream processors and 54 ray accelerators
• Cooling is provided by an active dual fan system
• The card uses a PCI Express 4.0 x16 interface
• Output ports include three DisplayPort 2.1 and one HDMI 2.1
• Maximum digital resolution is 7680 x 4320 pixels
• It supports DirectX 12 Ultimate and OpenGL 4.6
• Technology support includes VR Ready and AMD FreeSync
• The recommended system power supply is 750 W
• External power is provided via two 8-pin connectors
• Dimensions are 266 mm in length and 130 mm in height
• The total weight is 985 g
• Visual design includes white LED illumination
• The architecture features 48 MB of Infinity Cache
