Ports & interfaces | |
AC outlets quantity | 2 AC outlet(s) |
Power plug | Type F |
AC outlet types | Type F |
Weight & dimensions | |
Weight | 4.5 kg |
Package weight | 4.5 kg |
Height | 98 mm |
Width | 31 mm |
Depth | 138 mm |
Package depth | 346 mm |
Package height | 142 mm |
Package width | 222 mm |
Operational conditions | |
Operating altitude | 0 - 3000 m |
Operating relative humidity (H-H) | 0 - 95% |
Storage temperature (T-T) | -15 - 40 °C |
Operating temperature (T-T) | 0 - 40 °C |
Non-operating altitude | 0 - 3000 m |
Packaging data | |
Cables included | Input power cable |
Manual | |
Battery | |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 8 h |
Battery voltage | 12 V |
Battery capacity | 7 Ah |
Cold start | |
Battery life (max) | 2 year(s) |
Design | |
Certification | CB, CE, EN/IEC 62040-1, EN/IEC 62040-2 |
Form factor | Compact |
LED indicators | |
Product colour | Black |
International Protection (IP) code | IP20 |
Features | |
Response time | 6 ms |
Audible alarm(s) | |
Output power capacity | 0.7 kVA |
Surge energy rating | 273 J |
Noise level | 40 dB |
Input frequency | 50/60 Hz |
Output power | 360 W |
Surge protection | |
Input operation voltage (max) | 280 V |
Input operation voltage (min) | 170 V |
Output operation voltage (min) | 230 V |
Output operation voltage (max) | 230 V |
Output frequency | 50/60 Hz |
Input power factor | 0.51 |
Waveform | Sine |
Output voltage regulation | 10% |
Output frequency regulation | 0.5 Hz |
Automatic Voltage Regulation (AVR) | |
UPS topology | Line-Interactive |
Audible alarm modes | Alarm when on battery, Battery replacement, Low battery alarm, Overload alarm |
EAN | 731304404583 |
Warranty | 2 years |
Source: Icecat.biz |
Access monitoring
Detect access by unauthorized personnel via door switch.
Transformer-block spaced outlets
Protect equipment with input transformer blocks without blocking access to other receptacles.
Sleek design
Slim, modern design can be upright, flat, or wall-mounted to comfortably fit any electronics set-up and complement home décor.
Cold-start capable
Provides temporary battery power when the utility power is out.
Boost Automatic Voltage Regulation (AVR)
Preserves battery life and maximizes runtime by correcting low voltages without discharging the battery.
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Advanced Safety Features
Safeguard your Home UPS from overloads, excessive mains voltages, short circuits, installation mishaps and battery damage due to low voltage situations.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Battery backup and surge protection
Outlets provide abundant runtime for network gateway equipment and other critical low-power devices, allowing for hours of internet access during a power outage.
Battery and surge protected outlets
Back up and protect your hardware and data during power outages, surges and spikes.
LED Indicators
Provide easy-to-read status of the unit and utility power conditions.
Audible alarms
Provides notification of changing utility power and UPS power conditions
