HPE ProLiant DL360 Gen10 Performance - Palvelin - telineasennettava - 1U - 2-teinen - 1 x Xeon Gold 5218 / 2.3 GHz - RAM 32 GB - SATA/SAS - pikavaihto 2.5" - ei
Processor | |
Processor model | 5218 |
Number of processors installed | 1 |
Processor manufacturer | Intel |
Processor lithography | 14 nm |
Processor family | Intel Xeon |
Processor socket | P |
Supported instruction sets | AVX-512 |
Processor cores | 16 |
Processor threads | 32 |
Processor operating modes | 64-bit |
Processor boost frequency | 3.9 GHz |
Processor cache | 22 MB |
Execute Disable Bit | |
Scalability | 4S |
Tcase | 87 °C |
Embedded options available | |
Processor frequency | 2.3 GHz |
Thermal Design Power (TDP) | 125 W |
Processor codename | Cascade Lake |
Maximum number of PCI Express lanes | 48 |
Maximum internal memory supported by processor | 1.02 TB |
Memory types supported by processor | DDR4-SDRAM |
Memory clock speeds supported by processor | 2667 MHz |
Processor package size | 76.0 x 56.5 mm |
Memory | |
Internal memory type | DDR4-SDRAM |
Memory slots | 24x DIMM |
Maximum internal memory | 768 GB |
Memory layout (slots x size) | 1 x 32 GB |
Internal memory | 32 GB |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 4 |
VGA (D-Sub) ports quantity | 1 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
Weight & dimensions | |
Height | 42.9 mm |
Width | 434.6 mm |
Depth | 707 mm |
Energy management | |
Power supply | 800 W |
Redundant power supply (RPS) support | |
Number of redundant power supplies installed | 1 |
Networking | |
Ethernet LAN | |
Ethernet interface type | Gigabit Ethernet |
Storage | |
HDD interface | SATA |
Optical drive type | No |
RAID levels | 0, 1, 5, 6, 10, 50, 60 |
HDD size | 2.5" |
Hot-Plug support | |
Number of HDDs supported | 8 |
Maximum storage capacity | 22 TB |
RAID support | |
Operating system/software | |
Compatible operating systems | Windows Server 2012 R2 Windows Server 2016 VMware ESXi 6.0 U3 VMware ESXi 6.5 & U1 Red Hat Enterprise Linux (RHEL) 6.9 & 7.3 SUSE Linux Enterprise Server (SLES) 11 SP4 & 12 SP2 ClearOS CentOS |
Operating system installed | |
Expansion slots | |
PCI Express slots version | 3.0 |
Design | |
Rack mounting | |
Chassis type | Rack (1U) |
Product colour | Black, Silver |
Redundant fans support | |
Graphics | |
On-board graphics card model | Not available |
Processor special features | |
Intel® Hyper Threading Technology (Intel® HT Technology) | |
Intel® Turbo Boost Technology | 2.0 |
Intel® AES New Instructions (Intel® AES-NI) | |
Enhanced Intel SpeedStep Technology | |
Intel Trusted Execution Technology | |
Intel VT-x with Extended Page Tables (EPT) | |
Intel TSX-NI | |
Intel 64 | |
Intel Virtualization Technology for Directed I/O (VT-d) | |
Intel Virtualization Technology (VT-x) | |
Processor ARK ID | 192444 |
EAN | 0190017336459 |
Warranty | 1 year |
Source: Icecat.biz |
Does your data center need a secure, performance driven dense server that you can confidently deploy for virtualization, database, or high-performance computing?
The HPE ProLiant DL360 Gen10 server delivers security, agility and flexibility without compromise. It supports the Intel® Xeon® Scalable processor with up to a 60% performance gain and 27% increase in cores, along with 2933 MT/s HPE DDR4 SmartMemory supporting up to 3.0 TB with an increase in performance of up to 82%. With the added performance that HPE Persistent Memory, HPE NVDIMMs and 10 NVMe bring, the HPE ProLiant DL360 Gen10 means business. Deploy, update, monitor and maintain with ease by automating essential server life cycle management tasks with HPE OneView and HPE Integrated Lights Out 5 (iLO 5). Deploy this 2P secure platform for diverse workloads in space constrained environments.
What's new
- Enhanced iLO 5 security features such as Server Configuration Lock, iLO Security Dashboard and Workload Performance Advisor.
- HPE InfoSight provides a cloud-based analytics tool that predicts and prevents problems before your business is impacted.
- Supporting the second generation Intel® Xeon® Scalable processor family with up to a 11% per-core performance gain over first generation and with memory speeds up to 2933 MT/s.
- HPE Persistent Memory offers the flexibility to deploy as dense memory or fast storage featuring Intel® Optane™ DC Persistent Memory and enables per-socket memory capacity of up to 3.0 TB.
Features
Industry-leading Performance with Versatile Compute
HPE ProLiant DL360 Gen10 Server supports industry-standard technology leveraging the Intel Xeon Scalable processor with up to 28 cores, 12G SAS and 3.0 TB of 2933 MT/s HPE DDR4 SmartMemory.
HPE Persistent Memory works with DRAM to provide fast, high capacity, cost effective memory and storage to transform big data workloads and analytics by enabling data to be stored, moved, and processed quickly.
Achieve greater capacity with flexible drive configurations with up to 10 SFF and four LFF drives along with an option to support up to 10 NVMe PCIe SSDs delivering enhanced performance, capacity, and reliability to meet various customer segments and workload requirements at the right economics.
With support for up to 12 NVDIMMs per chassis and 2X capacity of first-generation HPE NVDIMMs, HPE ProLiant DL360 Gen10 Server delivers up to 192 GB per system.
Innovative Design for Flexibility and Choice
The premium 10 SFF NVMe chassis backplane provides the ability to mix and match SAS/SATA and NVMe within the same chassis along with 8 + 2 SFF and 4 LFF chassis that supports new uFF and M.2 storage options.
Embedded 4x 1GbE along with HPE FlexibleLOM or PCIe standup 1GbE, 10GbE, or 25GbE adapters provides flexibility of networking bandwidth and fabric so you can adapt and grow to changing business needs.
Unmatched expandability is packed in a dense 1U rack design with up to three PCIe 3.0 slots.
Security Innovations
HPE iLO 5 enables the world’s most secure industry standard servers with HPE Silicon Root of Trust technology to protect your servers from attacks, detect potential intrusions and recover your essential server firmware securely.
New features include Server Configuration Lock that ensures secure transit and locks server hardware configuration, iLO Security Dashboard helps detect and address possible security vulnerabilities and Workload Performance Advisor provides server tuning recommendations for better server performance.
With Runtime Firmware Verification the server firmware is checked every 24 hours verifying validity and credibility of essential system firmware. Secure Recovery allows server firmware to rollback to the to last known good state or factory settings after detection of compromised code.
Additional security options are available with Trusted Platform Module (TPM) to prevent unauthorized access to server and securely stores artifacts used to authenticate the server platforms while the Intrusion Detection Kit logs and alerts when the server hood is removed.
Industry-Leading Serviceability and Deployment
HPE ProLiant DL360 Gen10 Server comes with a complete set of services offered by HPE Pointnext, delivering confidence, reducing risk, and helping customers realize agility and stability.
Services from HPE Pointnext simplifies the stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an enhanced solution. Professional Services enable rapid deployment of solutions and Operational Services provide ongoing support.
Services provided under Operational Services include - HPE Flexible Capacity, HPE Datacenter Care, HPE Infrastructure Automation, HPE Campus Care, HPE Proactive Services and multi-vendor coverage.
HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.
