Produktspecifikation
Välj en eller flera funktioner för att söka efter produkter med samma specifikationer.Tekniska data | |
Hållbarhetscertifiering | Triman |
Garantiperiod | 10 År |
Anslutningar | |
Moderkort strömkontakt | 20+4 pin ATX |
Antalet SATA strömkontakter | 8 |
Periferiska (Molex) strömkontakter (4-pin) | 2 |
ATX strömkontakt (20 4 stift) | |
CPU strömkontakt (4 +4 pin) | |
PCI Express strömkontakter (6 +2 pin) | 3 |
Typ av kablage | Fully-Modular |
Längd, moderkortets strömförsörjningskabel | 55 cm |
SATA-nätkabelns längd | 550,750,450,650 mm |
CPU-strömkabelns längd | 70 cm |
Tillbehörsnätkabelns (Molex) längd | 450 mm |
Strömkontakt PCI Express (16 stift) | 1 |
Vikt & dimension | |
Höjd | 86 mm |
Bredd | 150 mm |
Djup | 140 mm |
Strömtillförsel | |
Ingående ström | 10 - 5 A |
Normalförbrukning | 750 W |
Effektivitet | 90% |
Hålltid | 16 ms |
Effekt skyddsfunktioner | No load operation, Over power, Over voltage, Overheating, Short circuit, Surge & inrush protection (SIP), Surge protection, Under voltage |
Power Factor Correction (PFC) typ | Aktiv |
Kombinerad effekt (+3,3 V) | 110 W |
Kombinerad effekt (+12 V) | 750 W |
Kombinerad effekt (+5 V) | 110 W |
Kombinerad effekt (-12V) | 3,6 W |
Kombinerad effekt (+5 VSB) | 15 W |
Max utström (+3,3 V) | 20 A |
Max utström (+12 V) | 62.5 A |
Max utström (+5 V) | 20 A |
Max utström (-12V) | 0,3 A |
Max utström (+5 VSB) | 3 A |
Växelström Frekvens | 50/60 hz |
AC-inspänning | 100 - 240 V |
Total effekt | 750 W |
Miljökrav | |
Temperatur vid drift | 0 - 40 ° C |
Förpackning | |
Förpackningstyp | Låda |
Certifikat | |
80 plus-certifiering | 80 PLUS Gold |
Förpackningens innehåll | |
Kabel inkluderad | AC |
Buntband inkluderat | |
Design | |
Produktens färg | Svart |
Antal fläktar | 1 fläkt/-ar |
På / av-knapp | |
Kylning typ | Aktiv |
Fläktdiameter | 12 cm |
Fan plats | Övre |
Prestanda | |
Medeltid mellan fel (MTBF) | 100000 h |
Ändamål | PC |
Kullagertyp | FDB |
ATX-version | 3.1 |
80 plus-certifiering | 80 PLUS Gold |
Strömförsörjningsenhet formfaktor | ATX |
EAN | 6933412719397 |
The DeepCool PN750M is a new power supply that meets the latest Intel ATX 3.1 and PCIe 5.1 standard. With a dedicated 12V-2x6, 5 EPS/PCIe ports, the PN750M provides stable power for a wide range of modern high-power components.
FUTURE PROOF
With the ability to provide twice the total system power for 0.1 ms, random power spikes will never be an issue. The PN750M will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.
GRACEFUL GOLD
80 Plus Gold certified to meet a high level of power efficiency under 90% of typical loads. Each unit is also rated Gold by Cybenetics.
POWER YOU CAN TRUST
Through the use of a main Japanese electrolytic capacitor, active PFC, full-bridge SRC LLC, and a DC-to-DC topology, the PN750M can keep the hold-up time to ≥ 16 ms under a high load of 80%.
PCI-E 5.1 POWER
Equipped with a high-grade 105C-resistant 16AWG copper-core embossed 12V-2x6 cable, the PN750M provides up to 450W for modern GPUs.
SLEEVED CABLES
The PN750M has been outfitted with sleeved cables right out of the box! A welcomed upgrade to add to the premium asesthic and feel of the PSU.
DYNAMIC FDB FAN
The PN750M comes equipped with a dynamic 120mm FDB fan that will adjust its speed based on the cooling needs of the PSU.
HIGH QUALITY BUILD
Due to the high quality of the parts utilized, the PN750M will operate at altitudes up to 5000 meters above sea level.
PEACE OF MIND
The PN750M comes standard with a slew of well-rounded safeguards, including OPP, OVP, SCP, OTP, OCP, UVP, NLO, and SIP.
EXCELLENT COVERAGE
The PN750M is engineered and manufactured at such a high level that DeepCool is offering a lengthy 10 years of trouble-free limited warranty coverage.
